Balance Hub

Traffic distribution at the speed of infrastructure, designed for zero-config scale, built for full-control flexibility

Project

Open Source

Type

HTTP
Load Balancer

Technology

Golang, SQLite, Redis

Load Balancer Reverse Proxy Self Hosted Scalable backend

Features

no restarts, no config reloads, no downtime.

BalanceHub is built on a dual listener architecture, a full HTTP(S) reverse proxy and a binary control-plane. Backend servers self-register at runtime with fine-grained routing rules, building a live routing table with zero manual intervention.

Dynamic Server
Registration

Response
Caching

Fault
Tolerant

Traffic
Management

Custom
Protocol

Aync
Logging

config.yaml — Full Config Schema

Original-Server:
  allow:                   # control-plane subnet allowlist
    - 192.168.1.0/24
    - 127.0.0.0/24
BalanceHub:
  listen:        5000      # HTTP reverse proxy port
  tcpListener:   5050      # control-plane TCP port
  protocol:      HTTP      # HTTP | HTTPS
  algorithm:     Least-Connected
  access-logs-path: ./logs
  db-path:       ''
  redis-server:
    ip:            127.0.0.1
    port:          6379
    caching:       false
    cache-duration: 900     # seconds

Configuration

A single config.yaml governs every runtime behavior, from port binding to TLS mode to Redis topology. The file is parsed once at startup into a typed Go singleton. Servers can declare path-level affinity (e.g., serve only /api/v2/) and client-IP restrictions (individual IPs or CIDR subnets)

Custom TCP Protocol

Backends join or leave the cluster at runtime over the TCP control plane. Registration writes atomically updating in-memory routing table simultaneously. Rather than exposing an HTTP management API, BalanceHub implements a compact binary protocol over a raw TCP socket. Session-level pipelining allows multiple operations in a single connection.

Request Packet (Layer 2001)

L magic

B magic

0xF0 action

len payload sz

JSON{…} mappings
